Schneider Electric
Compact NSX <630 undervoltage release MN - 48 V DC - LV429412
Out of stock
SKU
LV429412
Details
This is a MN undervoltage release for Compact NSX, PowerPact Multistandard and EasyPact CVS circuit breakers.
Its rated voltage is 48 VDC.
It is an auxiliary used for emergency off or remote opening applications.
This auxiliary opens the circuit breaker when the control voltage drops to a value below 35% of its rated voltage Un.
It complies with IEC 60947-2 standard.
This undervoltage release is a UL Listed/CSA Certified circuit breaker accessory.
Compact NSX, PowerPact Multistandard and EasyPact CVS can be equipped with either 1 MX or 1 MN auxiliary.
More Information
| Attribute | Value |
|---|---|
| SKU | LV429412 |
| range of product | ComPact NSX100...250, ComPact NSX400...630, ComPact NSX100...250 DC, ComPact NSX100...250 DC PV, ComPact NSX400...630 DC, ComPact NSX400...630 DC PV |
| product or component type | MCCB |
| mounting mode | fixed |
| device short name | MX |
| range | Aksesoris |
| [Uc] control circuit voltage | 48 V DC |
| range compatibility | ComPact NSX, EasyPact CVS, PowerPact Multistandard, ComPact NSX DC |
| voltage release type | undervoltage release |
| supply holding power | 5 W |
| auxiliary connection terminal | screw terminal 0-1.5 mm² |
| supply inrush power | 10 W |
| device application | control |
| response time | 50 ms |
| threshold tripping voltage | 0.35...0.7 x Un opening, 0.85 x Un closing |
