Schneider Electric
OsiSense XU pre-wired connectors XZ - straight female - M8 - 3 pins - cable PUR 5m - XZCP0566L5
Out of stock
SKU
XZCP0566L5
Details
This connection cable has a PUR cable (5 meter cable).
This pre-wired pigtail cable with one connector helps you to reduce your stock of spare process parts.
More Information
| Attribute | Value |
|---|---|
| SKU | XZCP0566L5 |
| product certifications | cULus |
| ambient air temperature for storage | -40-80 °C |
| ambient air temperature for operation | -40-80 °C static, -5-80 °C flexing |
| Cable length | 5 m |
| contact resistance | 5000 µOhm |
| range of product | Telemecanique Cabling components |
| product or component type | Detektor / Sensor |
| net weight | 0.12 kg |
| range | Proximity |
| accessory / separate part category | cabling accessory |
| electrical connection | straight female connector M8, 3 pins |
| status LED | without |
| IP degree of protection | IP65, IP69K, IP67 |
| [In] rated current | 4 A |
| [Ue] rated operational voltage | 60 V AC, 75 V DC |
| series name | general purpose |
| cable outer diameter | 5.2 mm |
| wire insulation material | PUR |
| cable composition | 3 x 0.34 mm² |
| accessory / separate part type | pre-wired connectors |
| collar material | metal |
| minimum insulating resistance | 1 GΩ |
| cable connector fixing | screw-on |
