Phaseo ABL8 battery - 24 V DC - 40 A - 7 AH - for battery control module - ABL8BPK24A07
This ABL8 backup battery (storage capacity 7 ampere hour) supplies direct current voltage.
It has a rated output current of 40A at 24V DC.
This backup battery (storage capacity 7Ah) is designed to provide continuous auxiliary power during significant and long network power shortages.
It provides long term backup power for power blackouts lasting more than a few seconds.
It weighs 6,030kg.
It is a functionnal module for power supply for industrial use, rail mounting.
It is certified by GOST, UL.
This functional module is mainly compatible with Modicon ABL8RP and Modicon ABL8WP Universal power supplies.
It has LED diagnostics indicator available in the front for troubleshooting instantly.
It installs on DIN rail.
It brings energy to your automated systems.
Designed for simple machines and applications, modular power supplies are primarily appreciated for their extreme compactness.
| Attribute | Value |
|---|---|
| SKU | ABL8BPK24A07 |
| product certifications | EAC, UL |
| ambient air temperature for storage | -20-50 °C |
| ambient air temperature for operation | 0-40 °C |
| range of product | Phaseo |
| product or component type | Relay & Power Supply |
| net weight | 6.5 kg |
| range | Power Supply |
| battery capacity | 7 Ah |
| output coupling | parallel |
| holding time | 2 mn, 30 s, 4 mn, 5 mn, 40 mn, 9 mn, 50 mn, 10 s, 15 mn, 6 mn, 3 mn, 1 h, 2 s, 30 mn, 5 s, 7 mn, 1 s, 2 h, 0.5 s, 1 mn, 20 mn, 8 mn, 10 mn, 5 h, 0.2 s, 3 h |
| compatibility code | ABL8B |
| marking | CE |
| input voltage limits | 21...29 V |
| operating altitude | 2000 m |
| load current | 0.7 A |
| self-discharge rate | 9 %, 3 months, 3 %, 1 month, 15 %, 6 months |
| holding current | 2 A, 8 A, 10 A, 6 A, 4 A, 5 A, 7 A, 1 A, 15 A, 3 A, 25 A, 20 A, 30 A, 35 A |
| holding solution | use of battery modules |
| charging time | 72 h |
